Ultra-compact, height 1.4 mm
Customizable operating force
Laptops & peripherals
Portable home devices, VR/AR
Robots, drones, industrial equipment, converters
RKE, steering, shifters, overhead consoles, car navigation, car audio, HVAC
| Items | Standard | |
|---|---|---|
| Operating temperature range | -40℃ to +85℃ | |
| Electrical performance | Rating | 50mA 12V DC |
| Insulation resistance | 100MΩmin.100V DC for 1 min | |
| Dielectric strength | 100V AC for 1 min | |
| Contact resistance | 100mΩ max | |
| Durability | Lifetime | 100,000 cycles |
| Mechanical performance | Operating force | J:160gf U:280gf H:400gf |
| Travel | 0.12 ± 0.05mm | |
