Ultra-compact, height 2.1 mm
Customizable operating force
Smartphones, tablets, headphones, wearables
Laptops & peripherals
Portable electronic devices
3C consumer electronics
| Items | Standard | |
|---|---|---|
| Operating temperature range | -40℃ to +85℃ | |
| Electrical performance | Rating | 50mA, 12V DC |
| Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| Dielectric strength | 100V AC for 1 min. | |
| Contact resistance | 100mΩ max. | |
| Durability | Lifetime | 100,000 Cycles |
| Mechanical performance | Actuating Force | J:160gf C:250gf I:520gf |
| Travel | 0.15 ± 0.05mm | |
