Ultra-small height of 2.5mm
Life up to over 1 million
Smartphones, Tablets, Headphones, Wearables, Laptops & Peripherals
Portable Electronic Devices
3C Products
| Items | Standard | |
|---|---|---|
| Operating temperature range | -40℃ to +85℃ | |
| Electrical performance | Rating | 50mA 12V DC |
| Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| Dielectric strength | 100V AC for 1 min | |
| Contact resistance | 100mΩ max | |
| Durability | Lifetime | 1,000,000 cycles |
| Mechanical performance | Operating force | J:160gf C:250gf |
| Travel | 0.25±0.1mm | |
