Ultra-compact, side-push type
Recessed mounting design
Smartphones, tablets, headphones, wearables
Laptops & peripherals
Remote keyless entry (RKE)
| Items | Standard | |
|---|---|---|
| Operating temperature range | -40℃ to +85℃ | |
| Electrical performance | Rating | 50mA. 12V DC |
| Insulation resistance | 100MΩ min. 100V DC | |
| Dielectric strength | 100V AC for 1 min. | |
| Contact resistance | 100mΩ max. | |
| Durability | Lifetime | J:200,000 cycles C:100,000 cycles |
| Mechanical performance | Operating force | J:160gf C:250gf |
| Travel | 0.15 ± 0.05mm | |
