THAM54-BJW-R1_MINI Series_Yueqing Kejian Electronics Co., Ltd.

THAM54-BJW-R1 MINI Series

列表.png Ultra-compact, side-push type

列表.png Waterproof rating equivalent to IP67

列表.png Smartphones, tablets, headphones, wearables, notebooks & peripheral devices

列表.png Healthcare devices

Items		Standard
Operating temperature range		-40℃ to +85℃
Electrical performance	Rating	20mA 15V DC
	Insulation resistance	100MΩ min. 100V DC for 1 min
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max
Durability	Lifetime	200,000 cycles
Mechanical performance	Operating force	160 ± 30 gf
Mechanical performance	Travel	0.12 ± 0.08mm
