硅胶按钮 (Silicone button)
操作声音小 (Less activation sound)
能源/工业: 工业设备 (Industrial Equipment)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩmin.100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 1,000,000 cycles |
| 机械性能 Mechanical performance | 操作力 Operating force | P:300gf W:350gf H:400gf |
| 行程 Travel | 0.50±0.3mm | |
