PS5810-B4_5.8*5.8_Yueqing Kejian Electronics Co., Ltd.

PS5810-B4 5.8*5.8

Product Features

列表.png The switch sounds silvery, feeling and rhythm are perfect;

列表.png Contact ways:SPDT & DPDT;

列表.png There are 2 operating modes:Self-Lock and Non-Lock;

列表.png The state of terminals and height of pushbutton can be designed according to customer's requirements;

Product Applications

列表.png The pushbutton switches can operate computer ancillary equipment, TV, audio equipment, all kinds of small autoimmunization equipment and instruments etc.

Ordering Information

Ordering Information.jpg

Technical parameter

Items		Standard
Operating temperature range		-20℃ to +70℃
Electrical performance	Rating	50mA. 30V DC
	Insulation resistance	100MΩ min. 100V DC
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	10,000 Cycles
Mechanical performance	Actuating Force	180 ± 50 gf
Mechanical performance	Travel	2.0 ± 0.30 m 1.2 ± 0.30 m
