MK-23D05 Side Push Type

列表.png Thin type 2.0mm in height.

列表.png SMT type and reflow-soldering for surface mounting.

列表.png Available for tape and reel package.

列表.png Function and band selector switches for headphone stereo sets, lquid-crystal TV sets, car radios, camera VCRs, MP3, memory cards, etc.

Items		Standard
Operating temperature range		-25℃ to +85℃
Electrical performance	Rating	100mA. 12V DC
	Insulation resistance	100MΩ min. 250V DC
	Dielectric strength	500V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	5,000 Cycles
Mechanical performance	Actuating Force	200 ± 100 gf
Mechanical performance	Travel	-
