MS-23C02_Top Push Type_Yueqing Kejian Electronics Co., Ltd.

MS-23C02 Top Push Type

列表.png Thin type 2.0mm in height

列表.png Some models are available for reflow-soldering

列表.png Function and band selector switches for headphone stereo sets, lquid-crystal TV sets, car radios, camera VCRs, MP3, memory cards, etc.

Items		Standard
Operating temperature range		-40℃ to +80℃
Electrical performance	Rating	100mA, 12V DC
	Insulation resistance	100MΩ min. 250V DC
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	5,000-10,000 Cycles
Mechanical performance	Actuating Force	180 ± 80 gf
Mechanical performance	Travel	3 level x 1.5
