有两种操作模式：自锁和无锁 (Two operation modes: self-locking and non-locking)
可回流焊接 (Reflow solderable)
计算机辅助与控制设备: 计算机辅助设备、各类小型自动控制设备及仪器 (Computer-aided equipment, various small automatic control devices and instruments)
音视频/电视: 电视、音频设备 (TVs, audio equipment)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 10mA 30V DC |
| 绝缘电阻 Insulation resistance | 100MΩmin.500V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 10,000 cycles |
| 机械性能 Mechanical performance | 动作力 Operating force | 180gf |
| 行程 Trigger Stroke | 1.20mm±0.30 mm | |
