硅胶按钮 (Silicone button)
操作声音小 (Less activation sound)
转向，换档器，顶置控制台 (Steering, shift lever, overhead console)
汽车导航仪，汽车音响，HVAC (Car navigation, car audio, HVAC)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +90℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 16V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 200,000 Cycles |
| 机械性能 Mechanical performance | 操作力 Operating force | B:180gf W:350gf |
| 行程 Travel | 0.75 ± 0.1mm | |
