防水等级相当IP67 (Waterproof rating equivalent to IP67)
SMT脚型设计 (SMT pin design)
能源/工业: 工业设备 (Industrial Equipment)
通讯/无线电: 对讲机 (Walkie Talkie)
家用: 白色家电, 办公设备 ( White Goods，Office Equipment)
音视频/电视: 画面 , 音响 , 专业音响 (Video, Audio, Professional Audio)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -20℃ to +70℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA, 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC | |
| 介电强度 Dielectric strength | 250V AC for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 Cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | 250 ± 50 gf |
| 行程 Travel | 0.20 ± 0.10 mm | |
| 返回力 Return Force | 50 gf min. | |
| 防水等级 Waterproof Rating | IPX7 equivalent | |
| 防尘等级 Dustproof Rating | IP6X equivalent | |
