防水等级相当IP67 (Waterproof rating equivalent to IP67)
输出脚可以作为引脚让电路设计更简单 (Output pins can be used as leads to simplify circuit design)
能源/工业: 工业设备 (Energy / Industrial: Industrial Equipment)
家庭: 白色家电, 办公设备 (Home: White goods, Office equipment)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 16V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 Cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | T:100gf |
| 行程 Travel | 0.7 ± 0.1 mm | |
