配备固定支架和多种结构及颜色的外壳；
高灵敏度，声音清脆，手感与节奏感完美；
可根据需求安装任意颜色的LED，包括双色或三色LED；
支持多种组装方式：DIP和SMT，同时兼容按键和轻触操作；
我们在新项目中已获得多项专利。
With a fixed stand and coversin many kinds of structure and color;
High sensitive sounds silvery, feeling and rhythm are perfect;
lt can be mounted with any color LED and double colors or 3colors LED according to preference;
lt can be assembled in different ways: DIP & SMT, with pushbutton an tact for operating;
We have got some patent for new project;
适用于各种电器，例如音频设备、办公设备、仪器仪表、电视、DVD等。
The switches work with all kinds of electrical appliances, such as audio apparatus, office equipment, instruments and meter equipment, TV, DVD and so on.
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -25℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 0.1A. 30V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 250V DC | |
| 介电强度 Dielectric strength | AC250V(50-60Hz) for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 Cycles |
| 机械性能 Mechanical performance | 操作力 Operating force | C:250gf G:300gf |
| 行程 Travel | 0.30 ± 0.1mm | |
