微型轻操作 (Microminiature, light operating)
手感良好且寿命长 (Good feeling and long life)
插入式设计，可直接安装在印刷电路板上，并具有良好的防静电性能 (Snap-in type, can be mounted directly on P.C. Board and good for electrostatic discharge)
拥有多种按钮形状和高度选择，适用于各种产品，安装方便 (It has a lot of choices for button shape and height and it is easily to install all kind of product)
Energy / Industrial:工业设备(Industrial Equipment)
Healthcare:健康器具, 分析检查器具(Health Appliances, Analytical and Inspection Equipment)
Home:办公设备(Office Equipment)
Audio / TV:画面, 音响, 专业音响(Display, Audio, Professional Audio)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -20℃ to +70℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 100mA, 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC | |
| 介电强度 Dielectric strength | 250V AC for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 Cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | 260 ± 50 gf |
| 行程 Travel | 0.25 ± 0.10 mm | |
