硅胶按钮 (Silicone buttons)
防止因振动产生的噪音 (Prevents noise caused by vibration)
输入设备 (Input Devices): 键盘, 鼠标, 触摸板 (Keyboard, Mouse, Touchpad)
音视频/电视 (Audio / TV): 画面, 音响, 专业音响 (Video, Audio, Professional Audio)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -20℃ to +70℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 100mA. 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC | |
| 介电强度 Dielectric strength | 250V AC for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | 1,000,000 Cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | 160 ± 30 gf |
| 行程 Travel | 0.25 ± 0.10 mm | |
