插脚类型可以直接安在PCB上 (Pin type can be directly mounted on PCB)
扣脚设计使结构更加牢固 (Snap-in design ensures a more secure structure)
能源/工业: 工业设备 (Industrial Equipment)
医疗保健: 健康器具, 分析检查器具 (Healthcare Devices, Analytical & Examination Instruments)
家用: 办公设备 (Office Equipment)
音视频/电视: 画面, 音响, 专业音响 (Video, Audio, Professional Audio)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | A: 300,000 cycles / C: 100,000 cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | A: 90gf, J: 160gf, C: 250gf |
| 行程 Travel | 0.25 ± 0.1 mm | |
