超薄型高度为0.9mm (Ultra-thin height: 0.9mm)
操作力度客制化 (Customizable operating force)
无人遥控器、音响、TV 音响、闪光灯 (Remote control, audio, TV speakers, flashlights)
电动牙刷 (Electric toothbrush)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +90℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 30,000 cycles |
| 机械性能 Mechanical performance | 操作力 Operating force | 1st: 80gf 2nd: 250gf |
| 行程 Travel | 1st: 0.25mm All: 0.4mm | |
