防水等级相当IP67 (Waterproof rating equivalent to IP67)
输出脚可以作为引脚让电路设计更简单 (Output pin can serve as a pin to simplify circuit design)
能源/工业: 工业设备 (Industrial Equipment)
医疗保健: 健康器具， 分析检查器具 (Health Appliances， Analysis and Inspection Equipment)
家用: 办公设备 (Office Equipment)
音视频/电视: 画面， 音响， 专业音响 (Video， Audio， Professional Audio)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 16V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | J:160gf C:250gf |
| 行程 Travel | 0.15 ± 0.05 mm | |
