插脚类型可以直接安在PCB上 (Plug-in type can be directly installed on PCB)
不同高度和力度可供选择 (Various heights and operating forces are available)
能源/工业: 工业设备 (Industrial Equipment)
医疗保健: 健康器具, 分析检查器具 (Healthcare equipment, Analytical and inspection equipment)
家用: 办公设备 (Office Equipment)
音频/电视: 画面, 音响, 专业音响 (Display, Audio, Professional audio)
汽车: 汽车导航仪 汽车音响 HVAC (Car navigation, Car audio, HVAC)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 16V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | J:160gf C:250gf |
| 行程 Travel | 0.20 ± 0.1 mm | |
