超薄型 (Ultra-thin type)
防水等级相当IP67 (Waterproof rating equivalent to IP67)
操作力度客制化 (Customizable operating force)
智能手机、平板电脑、智能音箱 (Smartphones, tablets, smart speakers)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +90℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC for 1 min | |
| 介电强度 Dielectric strength | 100V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 cycles |
| 机械性能 Mechanical performance | 操作力 Operating force | J:160gf V:200gf C:250gf P:300gf |
| 行程 Travel | 0.27 ± 0.10mm | |
