超小型、侧按 (Ultra-small, side press)
操作力度客制化 (Operating force customization)
消费电子: 智能手机，平板电脑，头戴式耳机，可穿戴设备，笔记本电脑及周边设备 (Smartphones, Tablets, Headphones, Wearable Devices, Laptops & Peripherals)
便携设备: 便携式电子设备 (Portable Electronic Devices)
3C产品: 3C产品 (3C Products)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩmin.100V DC for 1 min | |
| 介电强度 Dielectric strength | 100V AC for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 cycles |
| 机械性能 Mechanical performance | 动作力 Operating force | J:160gf C:250gf |
| 行程 Travel | 0.15±0.05mm | |
