超小型、侧按 (Ultra-compact, side actuation)
寿命高达100万以上 (Life expectancy over 1 million cycles)
移动设备: 智能手机、平板电脑、头戴式耳机、可穿戴设备、笔记本电脑及周边设备 (Smartphones, Tablets, Headphones, Wearables, Laptops & Peripherals)
便携式电子设备: 便携式电子设备 (Portable Electronic Devices)
3C产品: 3C产品 (3C Products)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -20℃ to +70℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA. 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC | |
| 介电强度 Dielectric strength | 250V AC for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | 50,000 Cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | 130 ± 30 gf |
| 行程 Travel | 0.30 ± 0.15 mm | |
