TVJM22 Waterproof Series

列表.png Waterproof rating equivalent to IP67

列表.png Output pins can be used as leads to simplify circuit design

列表.png Energy / Industrial: Industrial Equipment

列表.png Home: White goods, Office equipment

Items		Standard
Operating temperature range		-40℃ to +85℃
Electrical performance	Rating	50mA 16V DC
	Insulation resistance	100MΩ min. 100V DC for 1 min
	Dielectric strength	250V AC for 1 min
	Contact resistance	100mΩ max
Durability	Lifetime	100,000 Cycles
Mechanical performance	Actuating Force	T:100gf
Mechanical performance	Travel	0.7 ± 0.1 mm
