LS633 LED Series

Product Features

列表.png With a fixed stand and coversin many kinds of structure and color;

列表.png High sensitive sounds silvery, feeling and rhythm are perfect;

列表.png lt can be mounted with any color LED and double colors or 3colors LED according to preference;

列表.png lt can be assembled in different ways: DIP & SMT, with pushbutton an tact for operating;

列表.png We have got some patent for new project;

Product Applications

列表.png The switches work with all kinds of electrical appliances, such as audio apparatus, office equipment, instruments and meter equipment, TV, DVD and so on.

Ordering Information

Technical parameter

Items		Standard
Operating temperature range		-20℃ to +70℃
Electrical performance	Rating	100mA, 30V DC
	Insulation resistance	100MΩ min., 100V DC
	Dielectric strength	AC250V (50-60Hz) for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	100,000 Cycles
Mechanical performance	Operating force	250 ± 50 gf
Mechanical performance	Travel	0.25 ± 0.10 mm
