LS640-C5WR-U-G LED Series

Product Features

With a fixed stand and coversin many kinds of structure and color;
High sensitive sounds silvery, feeling and rhythm are perfect;
lt can be mounted with any color LED and double colors or 3colors LED according to preference;
lt can be assembled in different ways: DIP & SMT, with pushbutton an tact for operating;
We have got some patent for new project;

Product Applications

The switches work with all kinds of electrical appliances, such as audio apparatus, office equipment, instruments and meter equipment, TV, DVD and so on.

Ordering Information

Technical parameter

Items		Standard
Operating temperature range		-20℃ to +70℃
Electrical performance	Rating	DC 30V 100mA
	Insulation resistance	100MΩ min. DC100V
	Dielectric strength	AC250V(50-60Hz) for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	100,000 Cycles
Mechanical performance	Operating force	250 ± 50 gf
Mechanical performance	Travel	0.25 ± 0.10 mm
