With a fixed stand and coversin many kinds of structure and color;
High sensitive sounds silvery, feeling and rhythm are perfect;
lt can be mounted with any color LED and double colors or 3colors LED according to preference;
lt can be assembled in different ways: DIP & SMT, with pushbutton an tact for operating;
We have got some patent for new project;
The switches work with all kinds of electrical appliances, such as audio apparatus, office equipment, instruments and meter equipment, TV, DVD and so on.
| Items | Standard | |
|---|---|---|
| Operating temperature range | -25℃ to +85℃ | |
| Electrical performance | Rating | 0.1A. 30V DC |
| Insulation resistance | 100MΩ min. 250V DC | |
| Dielectric strength | AC250V(50-60Hz) for 1 min. | |
| Contact resistance | 100mΩ max. | |
| Durability | Lifetime | 100,000 Cycles |
| Mechanical performance | Operating force | C:250gf G:300gf |
| Travel | 0.30 ± 0.1mm | |
