ReturnTMHU26 Multifunction Series

Product Features

Sharp click feel with a positive tactile feedback;
Ultraminiature and light weight structure suitable for high density mounting, Economical but reliable;
lnsert molding in the contact with special treatment prevents flux build-up during soldering and permits auto-dipping.

Product Applications

Can be used to operate various multifunctional electronic devices, such as cameras, digital cameras, digital camcorders, and small portable devices etc.

Technical parameter

Items		Standard
Operating temperature range		-30℃ to +85℃
Electrical performance	Rating	10mA. 5V DC
	Output voltage	1V max. at 1mA 5V DC
	Contact resistance	100mΩ max.
Durability	Lifetime	100,000 Cycles
Mechanical performance	Operating force	Lever portion:70 ± 40gf Push portion:200 ± 100gf
Mechanical performance	Travel	Lever portion:-25° \| 0° \| 25° Push portion:0.90 ± 0.1mm
