Sharp click feel with a positive tactile feedback;
Ultraminiature and light weight structure suitable for high density mounting, Economical but reliable;
lnsert molding in the contact with special treatment prevents flux build-up during soldering and permits auto-dipping.
Can be used to operate various multifunctional electronic devices, such as cameras, digital cameras, digital camcorders, and small portable devices etc.
| Items | Standard | |
|---|---|---|
| Operating temperature range | -30℃ to +85℃ | |
| Electrical performance | Rating | 50mA. 12V DC |
| Insulation resistance | 100MΩ min. 100V DC | |
| Dielectric strength | 250V AC for 1 min. | |
| Contact resistance | 4-direction:200mΩ max. Center push:100mΩ max. | |
| Durability | Lifetime | 50,000 Cycles |
| Mechanical performance | Operating force | 4-direction:140 ± 50gf Center push:220 ± 80gf |
| Travel | 4-direction:5° ± 2° Center push:0.20 ± 0.1mm | |
