THDP35 6.0*6.0 Series

Product Features

列表.png Microminiature, light operating;

列表.png Goodfeeling and long life;

列表.png Snap-in type, can be mounted directly on P.C. Board and good for electrostatic discharge;

列表.png lt has a lot of choices for button shape and height and it is easily to install all kind of product.

Product Applications

列表.png They can operate all types of electronic equipment such as the telephone, PDA, DVD, digital camera, audio equipment, instrument and meter equipment, autoimmunization equipments control etc.

Ordering Information

Technical parameter

Items		Standard
Operating temperature range		-20℃ to +70℃
Electrical performance	Rating	50mA. 12V DC
	Insulation resistance	100MΩ min. 100V DC
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	50,000 Cycles
Mechanical performance	Actuating Force	260 ± 70 gf
Mechanical performance	Travel	0.30 ± 0.10 mm
