Surface mount type
Different heights and forces available
Industrial Equipment
Health Appliances, Analysis & Inspection Instruments
Office Equipment
Video, Audio, Professional Audio
| Items | Standard | |
|---|---|---|
| Operating temperature range | -40℃ to +85℃ | |
| Electrical performance | Rating | 50mA. 12V DC |
| Insulation resistance | 100MΩ min. 100V DC | |
| Dielectric strength | 250V AC for 1 min. | |
| Contact resistance | 100mΩ max. | |
| Durability | Lifetime | 100,000 Cycles |
| Mechanical performance | Actuating Force | 250 ± 50 gf |
| Travel | 0.25 ± 0.12 mm | |
